Dual Pro Eagle I-3620 36 volt 20 Amp Battery Charger

36 Volt 20 Amp Commercial Grade Battery Charger.

The Dual Pro Eagle I-3620 36 volt 20 Amp battery charger is an industrial grade 36 volt battery charger, with fan cooling and temperature compensation of the output voltage. The Eagle series are heavy duty, microprocessor controlled, thermally protected battery chargers. They are portable or bench top chargers, with a handle. They are available with alligator clips, or an Anderson connector of the appropriate size and color. 36 volt systems usually use the 50 amp gray Anderson SB50 connector, and this will be supplied unless specified otherwise.

The Dual Pro Eagle series combine the reliability of a heavy duty transformer, with a microprocessor controller, for long term performance and proper battery management. With temperature compensation and computer control, a quicker, more efficient charge cycle results in complete battery charge, better battery life, and less water loss in flooded batteries. They are safe for the sealed lead acid batteries as well. The LED array on the charger case indicates status of the battery.

The Eagle series are made in the US, and feature a 3 year warranty. The I-3620 Eagle 36 volt 20 amp battery charger is suitable for medium use 36 volt systems, including floor scrubbers, golt carts, personnel carts, cargo carts, scissor lifts, and other industrial equipment. Battery capacities from about 100 amp hours and up are appropriate for this charger, depending on use and desired recharge time.

For more information see our Battery Charging Tutorial

   Click image for larger picture, "Back" button to return

Eagle I-3620 Part#: I3620

Dual Pro 36 Volt 20 Amp
Eagle Charger


Specifications:  Features:
Dim (LxWxH):9.75 x 8.38 x 8.25 Handle
Actual Weight:21.0 Thermal Protection
Ship Weight:23.0 Reverse Polarity Protection
AC Input:115 VAC @ 10 amps Temperature Compensation
DC Output:20 Amps Spark Free Hookup
Temp Range:32F to 113F Short Circuit Protected
Float Voltage:40.5 LED Readout
Approvals:UL 1564 Pending Made In USA
Warranty:3 Years

Will ship with the voltage correct Anderson SB50 connector unless
otherwise specified.

Be sure to see our battery charging tutorial.
