This Dual Pro Eagle 36 volt 12 Amp golf cart charger is an industrial grade 36 volt battery charger, with fan cooling and temperature compensation of the output voltage. The Eagle series are heavy duty, microprocessor controlled, thermally protected battery chargers, encased in a heavy duty case. They can be portable or bench top chargers, with a handle. This model for golf carts or other applications ships with the gray Anderson SB50 connector for carts or others that use this connector. Other color and amperage Anderson connectors are available, so call if you have a differing requirement.
The Dual Pro Eagle series combine the reliability of a heavy duty transformer, with a microprocessor controller, for long term performance and proper battery management. With temperature compensation and computer control, a quicker, more efficient charge cycle results in complete battery charge, better battery life, and less water loss in flooded batteries. They are safe for the sealed lead acid batteries as well. This golf cart charger, goes into a float mode when the charge is complete, for long term battery maintenance. The LED array on the charger case indicates status of the battery.
The Eagle series are made in the US, and feature a 3 year warranty. The Eagle 36 volt 12 amp golf cart charger is suitable for moderate use 36 volt carts which are not run dead every day. Heavy use carts or carts in industrial applications will be better served by the 25 amp version.
For more information see our Battery Charging Tutorial
Eagle 36 Volt 12 Amp
with gray SB50
|Dim (LxWxH):||9.75 x 8.38 x 8.25||Handle|
|Actual Weight:||20.0||Thermal Protection|
|Ship Weight:||21.0||Reverse Polarity Protection|
|AC Input:||115 VAC @ 6 Amps||Temperature Compensation|
|DC Output:||12 Amps||Spark Free Hookup|
|Temp Range:||32F to 113F||Short Circuit Protected|
|Float Voltage:||40.5||LED Readout|
|Approvals:||UL 1564 Pending||Made In USA|
